Introducing the EcoFlow 30A/50A Distribution Panel - Gen 2, a game-changing solution that brings convenience and versatility to your power distribution needs. This innovative panel is designed to streamline the management of AC and DC power, making it the perfect companion for both indoor and outdoor applications.
One of the standout features of the new EcoFlow 30A/50A Distribution Panel - Gen 2 is its ability to accommodate both AC (alternating current) and DC (direct current) power sources and allow up to 240V output when connected to 50A shore power.
This distribution panel can be wired to support just single-phase 120VAC loads, or to support both single-phase 120VAC and split-phase 240VAC loads. It also supports either 12VDC or 24VDC output.
FREE SHIPPING on this item anywhere in the lower 48 US states.
Feed-In type | Split phase (L1, L2, N) |
AC Input | 50A Max. 120V/240V, 60Hz |
AC Output | Max 30A for each branch circuit |
AC Circuits | Max 12 branch circuits |
Maximum Input Short-Circuit Current | 10kA |
DC Input | Max 100A, 13/26V |
DC Output | Max 30A for F1-F13 Circuits Max 50A for F14-F16 |
Number of Circuits | 16 controllable circuits(F1-F16) |
Operating Temperature (C) | –25°C to 45°C (–13°F to 113°F) |
Operating Temperature (F) | –25°C to 70°C (–13°F to 158°F) |
Dimensions | 390x135x270 mm (15.3x5.3x10.6 in.) |
Net Weight (lbs) | 4 kg (8.8 lb) |
Altitude | 9842 ft (3,000 m) |
Enclosure Type | NEMA Type 1 |
